Electrical Control Valves

These pressure control valves for variable displacement compressor for vehicle air condition systems are lightweight and compact in size.

The EKK-specially designed structure achieves perfect pressure balance by canceling internal pressure.

Fitted with DPS(Direct pressure sensing), an EKK patented development.

Product photos

Features

  • Pressure control valves for automotive air-conditioning variable displacement compressors.
  • Controls compressor pressure and rotational load to improve the fuel consumption.
  • EKK's proprietary mechanism incorporating an evacuated metal bellows in the pressure sensing part.

These pressure control valves for variable displacement compressor for car air condition systems are lightweight and compact in size.

The electronical control valve is an EKK-specially designed structure which achieves perfect pressure balance by canceling internal pressure. This valve is fitted with DPS(Direct pressure sensing), an EKK patented development.

Product specifications

Item

Range

Unit

Voltage

Rated voltage 12.0 (13.5 max.)

V

Temperature

120 for continuous exposure (150 max. and -40 min.)

°C

Pressure

2.0 max.

(characteristics guaranteed at this pressure; breakdown pressure: 9.0 MPaG)

MPaG

Resistance

10.6 ± 0.5

Ω

Note: The figures above show some examples. Contact us when you are considering making a purchase.
